FC Square mount configurations fIber adapter

Share to:

Description

FC Square mount configurations fiber adapter are developed to couple and mate two FC connector plugs. The housing of the Adapters of the last generation has a reference key for the right position coupling and zirconia or phosphorus bronze split sleeve for high alignment.



OMC Adapters design, material and manufacturing process assure long life and high repeatability of optical performances even for different brand connectors mating.



Features:

  • NTT-FC compatibility
  • Corrosion resistant housing
  • Precision connection with sleeve
  • SM and MM connector can be used interchangeably
  • Low insertion loss, High Return loss
  • Good interchangeability and reliability
  • Meet IEC and ROHS standards
  • High precision of mechanical dimensions Accuracy

Specification

Test item (SM-9/125) UPC (SM-9/125) APC MM PC
Insertion Loss ≤0.2dB ≤0.2dB ≤0.2dB
Return Loss ≥50 dB ≥60 dB ≥35 dB
Durability (1000 Mating) 0.1dB typical change
Withdrawal force(g/f) 2.0N ~ 5.9N (200gf ~ 600gf)
Storage Temp(℃) -40~+85



Material

Parts name Material Color
Housing body Nickel-plated brass or nickel-plated zinc
Sleeve High precision Ceramic sleeve White
Dust Cover Rubber Red/Black/Green/White

Available for Simplex of SM UPC, SM APC, MM OM1 62.5/125, MM OM2 50/125



Application:

  • Patch panels, ODF and other optical connections.
  • Optical networks demarcation and monitoring point
