OP(SC ) waterprood Adapter

Share to:

Description

Mini IP SC Waterproof adapter are developed to couple and mate two Mini IP SC connector plugs. Our range of high-quality SC adapters have high precision alignment sleeves for reliability and improved reconnect ability. For single mode and multimode applications, a ceramic sleeve is supplied. The housing is available in different colors with options for flange or flangeless body, metal clips or inbuilt clips. A protective cap is provided at each end of the adapter with the same color as the adapter



OMC Adapters design, material and manufacturing process assure long life and high repeatability of optical performances even for different brand connectors mating.



Features

  • Complies with IEC 61754-4 standard
  • Available in Flanged and Flangeless options
  • Push-pull locking mechanism for easy installation
  • Precision connection with sleeve
  • SM and MM connector can be used interchangeably
  • Low insertion loss, High Return loss
  • Good interchangeability and reliability
  • Meet IEC and ROHS standards
  • High precision of mechanical dimensions Accuracy

Specification

Test item (SM-9/125) UPC (SM-9/125) APC MM PC
Insertion Loss ≤0.2dB ≤0.2dB ≤0.2dB
Return Loss ≥50 dB ≥60 dB ≥35 dB
UL Rating: UL 94-V0
Withdrawal force (g/f) 2.0N ~ 5.9N (200gf ~ 600gf)
Storage Temp(℃) -40~+85
Protection level IP67 or IP68



Products Materials

Parts name Material Parts name Material
Adapter body PC Adapter body screw PA66+15%GF
Sleeve High precision Ceramic sleeve Sling PA66+15%GF
Waterproof Dust Cover PA66+15%GF Waterproof gasket Silica gel
Dust Cover PBT Spring Sus304
